    3L 75mm Fully Automatic Blow Molding Machine 4.8t Plasticization HDPE Bottle

    Ask Lasest Price
    Brand Name : DAWSON
    Model Number : ABLB75II
    Certification : CE
    Price : USD 25,000 ~ 40,000 / set
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 20-30 sets / month
    Delivery Time : 35-45 working days
    • Product Details
    • Company Profile

    3L 75mm Fully Automatic Blow Molding Machine 4.8t Plasticization HDPE Bottle

    Automatic 5L HDPE Household Bottle Blow Molding Machine


    DAWSON MACHINERY& MOULD GROUP
    Automatic Extrusion Blow Molding Machine
    ABLB75II

    U Product: 0~5 L Bottles

    U Power supply: 380/220V 50/60 Hz Tri-phase

    U Die head number: Single / Double

    U Suitable raw material: PE, PP, PVC, PS, PETG

    U Output capacity: 220~240 PCS/h (5L) / with single head

    450~480 PCS/h (1L) / with double head

    Basic parametersSuitable materialHDPE. PP, PVC, PS, PETG, so on
    Max volume5L (Single head) / 1L double die head
    Output capacity220~240 PCS/h
    Size3.8×2.3×2.5(M)
    Weight4.8T
    SystemSpecificationParametersNote
    Plasticizion system
    SummarizeHigh efficient low power consumption plasticizion system, transducer control, self-protect function when started at low temperature
    ReducerMaterial of Gear box body: HT200
    Material of gear: ZG35CrMo
    Material of bearing: 42CrMo
    Heat treatment of Gear: Quenching
    Brand: GuoTai
    (The best Gearbox supplier in China)
    Screw75mm, L/D ratio 25/1,
    Material: 38CrMoALA
    Nitriding heat-treatment
    Cooling by cooling Fan
    Cooling system available
    Plasticization100Kg/HHDPE
    Heating Zone3-4 Aluminum HeaterAutomatic heating
    Heating power4KW/H
    Extrusion MotorThree phase asynchronous motor (380V, 50Hz) 30HPBrand: Siemens
    Cooling Fan3-4zoneAutomatic cooling


    Extrusion system
    SummarizeHigh-grade alloy steel, center feeding
    Avaible to change to double die head or thriple die heads
    Die head numberSingle head for 5L / double head for 1L
    Center distance of die heads130mm or 160mm for Double die head
    75mm or 80mm for Four die head
    Die headMaterial of the die Head: 38CrMoAlA+40Cr+45# Steel
    Die head corn mirror degree
    We provide complete set die for each sample free
    Heating3-4 Stainless steel heating cycle
    With Plug type heater
    High quality thermocouple for temperature checking
    Plug type heater more easy and convinient for changing die heads
    Heating power3~5KW
    Clamping systemAutomatic Lubricant system for clamping system
    Clamping force80KN
    Template distance150~560mm
    Max mould size400X450mm
    Platen moving stroke520mm
    LubricationEquiped with automatic lubrication system























    Electric system
    SummarizePLC+ touch screen(man-machine interface)standard extrusion blow molding machine controlling system(AUTO monitoring, fault-alarm, auto counting, auxiliary function available)Siemens or MITSUBISHI PLC
    System + TOUCH SCREEN
    Operate interfaceTouch screen, automatic self-diagnose alarm system
    Temperature controlAutomatic temperature control moduleSiemens OR MITSUBISHI MODULE
    Electrical partsSchneider electricals & Omron relay
    Electric protectionAmpere overload, electric short circuit self-protection function
    Parison controllerJapan MOOG 100 points parison controller + Moog servo Valve + stainless oil tank + oil pipes & fittings
    (Optional: 10500 USD/ complete set if needed )
    InvertorDELTA (Taiwan) 380V50Hz
    One for main screw + another for lever line screw
    Hydraulic systemSummarizeMultiple function hydraulic integrated block Proportional control, high efficient
    Oil pump motorThree phase asynchronous motor (380V, 50Hz) 7.5kw
    Oil pumpImported double pump
    ValvesJapan YUKEN Hydraulic valves
    YUKEN Hydrulic valve
    Precision control
    More safe and easy to operate and maintenance
    Also YUKEN series avoid any leakage problem both inner or outter, which makes the all operation reliable and safe.
    O-sealings
    High quality O-sealings
    We provide spare parts for each sealings
    Oil pipesDouble layer overpressure resistant
    System pressureLP 100 bar / HP 130 bar
    Threads of hydraulic block use of screw joint GE(ISO 1179)
    Cooling systemSeparate water cooling cycle, oil cooler cooling system
    High quality Oil cooler
    Pneumatic systemSummarizeTaiwan AIRTAC pneumatic system
    Air pressure0.8MPa
    Air displacement0.8M3/min
    Electromagnetic valveAIRTAC
    Cooling systemSummarizeSeparate cooling system of mould, barrel and oil system
    Cooling mediumWater
    Water flow80L/min
    Water pressure0.3-0.6MPa

    3L 75mm Fully Automatic Blow Molding Machine 4.8t Plasticization HDPE Bottle


    #blow molding machine #Extrusion Blow Molding #Injection blow molding machine #PET blow molding machine # injection molding machine # blowing mould # plastic bottle making machine#plastic bottle mould #bottle machine #plastic machinery #blow molding mould #moulding machine # moulding mould #China blow molding machine #blow molding machine made in China


    Type of Blow Molding Machine


    Extrusion blow molding
    In Extrusion Blow Molding (EBM), plastic is melted and extruded into a hollow tube (a parison). This parison is then captured by closing it into a cooled metal mold. Air is then blown into the parison, inflating it into the shape of the hollow bottle, container or part. After the plastic has cooled sufficiently, the mold is opened and the part is ejected.

    EBM processes may be either continuous (constant extrusion of the parison) or intermittent. Types of EBM equipment may be categorized as follows:

    1. Continuous Extrusion Equipment

    • Rotary wheel blow molding systems
    • Shuttle machinery

    2. Intermittent Extrusion Machinery

    • Reciprocating screw machinery
    • Accumulator head machinery

    Examples of parts made by the EBM process include dairy containers, shampoo bottles, and hollow industrial parts such as drums.

    Basic polymers, such as PP, HDPE, PVC and PET are increasingly being co-extruded with high barrier resins, such as EVOH or Nylon, to provide permeation resistance to water, oxygen, CO2 or other substances. In dairy applications, it is possible to extrude a black light-blocking layer in the center layer of containers, with opaque white resin used in the inner and outer layers.
    Compared to injection molding, blow molding is a low pressure process, with typical blow air pressures of 25 to 150 psi. This low pressure process allows the production of economical low-force clamping stations, while parts can still be produced with surface finishes ranging from high gloss to textured. The resulting low stresses in the molded parts also help make the containers resistant to strain and environmental stress cracking.

    Accumulator Head Machinery is used for the extrusion blow molding of large industrial hollow parts. Examples of parts produced on this machinery include drums, trash cans, automotive panels, playground equipment, and large containers, such as Jerry Cans, for liquid storage. Most parts produced on accumulator head machinery are single layer; however, specialized machinery is capable of producing parts with up to seven unique layers of plastic - these machines are used primarily to manufacture automotive gasoline tanks with barrier layers.

    Plastic machines we provide ....

    Extrusion Blow Molding Machine

    Injection Blow Molding Machine

    PET Blow Molding Machine

    Injeciton Molding Machine

    Injection Stretch Blow Molding Machine
    Applictions ....

    Chemicals : Pesticide bottles and industrial buckets, chemical buckets and other hollow blow-molded buckets.

    Cosmetics&Pharmaceuticals : Vaccine bottles, medicine bottles, medical bed boards, cosmetic boxes, jars and vaseline bottles and other plastic machinery products used in cosmetic and medical fields.

    House hold : Plastic empty blow-molded bottles, plastic containers, such as shower gel bottles, shampoo bottles, body lotion bottles, laundry detergent bottles, cleaning supplies bottles, hand sanitizer bottle, disinfectant bottle, alcohol disinfectant bottle etc. that are often used in daily life.

    Indoor & outdoor : Plastic products are widely used, such as plastic hollow flower pots, plastic watering cans, plastic pet houses, plastic cold storage boxes, plastic children's toys, plastic-bus chairs, plastic tables and chairs, plastic trash cans, plastic traffic cones, plastic life buoys, plastic floats , Plastic buoys, plastic mannequins, etc., plastic machinery products can be seen everywhere.

    Food & Beverage : The common applications of plastic products in the food and beverage industry are ketchup bottles, soy sauce bottles, honey bottles, mustard sauce bottles, milk bottles, yogurt bottles, juice bottles, alcohol bottle etc. Baby bottles are also common in plastic machinery in the beverage and food industry Applications.

    Lubrication : The most common applications for hollow extrusion blow molding machines are lubricating oil barrels, 1L 2L lubricating oil bottles, 5L 10L cans, 10L 20L 25L to 30L lubricating oil Jerry can, and even 60L ~ 250L large barrels.

    Automotive : The application of plastic products also accounts for a large part of automobile parts, such as plastic parts in automobile engines, plastic automobile safety stalks, plastic door handles, plastic car lamp housings, etc.
