    Double Station Double Die Head Plastic HDPE 5L 10L EURO ADBLUE Canister Blow Molding Machine

    Ask Lasest Price
    Brand Name : Dawson
    Certification : CE
    Price : USD 32900-34200
    Payment Terms : L/C, T/T
    • Product Details
    • Company Profile

    Double Station Double Die Head Plastic HDPE 5L 10L EURO ADBLUE Canister Blow Molding Machine

    Double Station Double Die Head Plastic HDPE 5L 10L EURO ADBLUE Canister Blow Molding Machine

    Double Station Double Die Head Plastic HDPE 5L 10L EURO ADBLUE Canister Blow Molding Machine

    5-10L Jerry Can Blow Molding Machine

    In the highly competitive plastic manufacturing industry, the 5 - 10L Double Station Double Die Head Jerry Can Blow Molding Machine stands out for its remarkable production efficiency and cost - effectiveness.​
    Increased Output​
    As mentioned earlier, the dual - station and double - die - head design enables a substantial increase in production output. This not only allows manufacturers to meet larger orders but also helps in reducing the per - unit production cost. When producing in larger volumes, the fixed costs associated with running the machine, such as energy consumption, maintenance, and operator labor, are spread over a greater number of units.
    The ability to accurately control the wall thickness of the parison means that just the right amount of plastic is used for each jerry can. In traditional blow - molding machines, over - extrusion or inconsistent wall thickness often leads to wasted plastic. With the 5 - 10L Double Station Double Die Head machine, the waste percentage can be reduced to as low as 5%, compared to 10 - 15% in some older models. This not only saves on material costs but also has environmental benefits by reducing plastic waste.​
    Energy - Saving Features​
    Modern versions of this blow - molding machine are designed with energy - efficiency in mind. Servo - motor - driven systems are increasingly being used instead of traditional hydraulic systems. Servo motors consume less energy as they only draw power when required, unlike hydraulic systems that run continuously. Additionally, the heating and cooling systems are optimized to reduce energy consumption. For example, intelligent temperature control systems can adjust the heating power based on the actual temperature of the plastic, preventing over - heating and unnecessary energy usage. These energy - saving features can result in a 20 - 30% reduction in overall energy consumption, which is a significant cost savings over time.​
    Fast Change - Over Times​
    In a dynamic manufacturing environment, the ability to quickly switch between different jerry can designs or sizes is crucial. The 5 - 10L Double Station Double Die Head machine is designed with easy - to - change molds. The mold - changing process can be completed in a relatively short time, usually within 15 - 30 minutes. This is much faster than some older models that may take an hour or more. The quick change - over times mean that manufacturers can respond more rapidly to market demands, producing different types of jerry cans as needed without significant downtime.

    Double Station Double Die Head Plastic HDPE 5L 10L EURO ADBLUE Canister Blow Molding Machine

    SPECIFICATIONSUNITSDSB90II
    Stationdouble
    Max product volumeL10
    Number of die headsSet1/2/3/4/6
    Dry cyclePC/H700*2
    Machine dimension (L*W*H)M4.4*2.2*2.7
    Total weightTon11
    CLAMPING UNIT
    Clamping force
    		KN160
    Platen opening stroke

    mm

    		290-680
    Platen sizemm550*530
    Max mould size (W*H)mm550*530
    Platen moving distancemm620
    POWER
    Extrusion motor powerKW45
    Oil pump motor power18KW18.5
    Extrusion heating powerKW16
    Head heating powerKW8-10
    Total powerKW87.5-89.5
    EXTRDER UNIT
    Screw diametermm90
    Screw L/D ratioL/D25
    Plasticizing capacityKg/hour150
    Number of heating zoneZone4
    Max die mouth diameter(single head)mm200

    Double Station Double Die Head Plastic HDPE 5L 10L EURO ADBLUE Canister Blow Molding MachineDouble Station Double Die Head Plastic HDPE 5L 10L EURO ADBLUE Canister Blow Molding MachineDouble Station Double Die Head Plastic HDPE 5L 10L EURO ADBLUE Canister Blow Molding MachineDouble Station Double Die Head Plastic HDPE 5L 10L EURO ADBLUE Canister Blow Molding MachineDouble Station Double Die Head Plastic HDPE 5L 10L EURO ADBLUE Canister Blow Molding MachineDouble Station Double Die Head Plastic HDPE 5L 10L EURO ADBLUE Canister Blow Molding MachineDouble Station Double Die Head Plastic HDPE 5L 10L EURO ADBLUE Canister Blow Molding MachineDouble Station Double Die Head Plastic HDPE 5L 10L EURO ADBLUE Canister Blow Molding MachineDouble Station Double Die Head Plastic HDPE 5L 10L EURO ADBLUE Canister Blow Molding MachineDouble Station Double Die Head Plastic HDPE 5L 10L EURO ADBLUE Canister Blow Molding MachineDouble Station Double Die Head Plastic HDPE 5L 10L EURO ADBLUE Canister Blow Molding MachineDouble Station Double Die Head Plastic HDPE 5L 10L EURO ADBLUE Canister Blow Molding Machine

    DAWSON MACHINE & MOULD GROUP


    located in Zhangjiagang city, have more than 18 years' experience in the field of plastic machinery,
    injection molding machine, blow molding machine, PET blow molding machine, injection blow molding machine, during the past 18 years, we always force our energy into new areas of plastic machinery, plastic packaging machinery, to update the technology, to learn advanced experience, to confirm new theory and new design, we are forming a unique competitive advantage of our owns.
    The machines from our company carry good quality and effective after-sales service, upon the market,
    customers from more than 45 countries, we provide complete solution for your plastic industry
    business, as well as all sorts of technical support & after-sale services!
